MULTILED L190X

Key features

Color and Lenses

Changeable Lens

White LED

Color LED

Operating mode

Continuous

Strobe

Overdrive

Specs

1.800.000 lm overdrive

Housing variants

IPxx options

Technical features

• For pulsed operation at low duty cycle only. With 30.000 W LED power, e.g. at 10 kHz and 1 µs exposure time

 only 300 W are used.

• Power consumption limited to 2.000 W

• White or Color LED

• Very homogenous illumination

• Preinstalled lens (horizontal x vertical): 18°x18°

• Additional lenses (horizontal x vertical): 27°x27° - 45°x45° - 63°x63° - 35°x19° - 63°x18°

• Power supply 600 W with 5 m cable included


For more Options with GX8 see Datasheet



State of the art LED Technology

MultiLED produts cover all applications of high speed cameras and many applications in the machine vision market. Some family members e.g. cover sub microsecond exposure time, monochromatic light or give you enough light to fully close aperture at some microseconds exposure time.
Designed from a decade of experience with thousands of customer projects in mind, MultiLed products off er ultra strong lighting at an affordable price.
